Disassembly and Reassembly Guidelines and Rules

/in /by

By: Natalie Arevalo (Design & Manufacturing Engineer)

Approved by: Lucas Gutierrez (Project Manager)

Table of Contents

Introduction

The customer requested for there to be specific rules and guidelines for the disassembly and reassembly portion during the day of Mission Launch. In order to compile a comprehensive list of rules and guidelines, a set of questions were sent to the project managers in regards to disassembly and reassembly. With the initial input from the project manager, an initial document was composed outlining the intended rules and guidelines. After a brief review of this document by the project managers, minor adjustment were made to the list. The current list of the rules and guidelines for disassembly and reassembly are listed below.



Guidelines and Rules

Time Allotted

  • Disassembly: 10 minutes
  • Reassembly: 10 minutes



Rules for Dissassembly

  1. All robot will be disassembled by the E&C and Manufacturing engineers – 2 engineers in total.
  2. All teams will disconnect all electronics connected to the 3Dot board.
    1. All 3Dot boards will be clear of electronics
  3. All teams will disconnect motors
  4. Project specific disassembly guidelines:
    1. Sojourner
      1. Disassemble rover body
      2. Disassemble suspension system
      3. Disconnect all sensors
    2. Goliath
      1. Remove panels
      2. Remove tracks
      3. Disconnect all sensors
    3. P-Bot
      1. Disassemble robot body
      2. Disconnect wheels
      3. Disconnect all sensors
    4. ModWheels
      1. Disconnect wheels and front axle
      2. Disassemble chassis
      3. Disconnect all sensors



Rules for Assembly

  1. All robots will be reassembled by the E&C and Manufacturing engineers – 2 engineers total.
  2. All teams will be allowed to use a cable tree as well as an assembly diagram as necessary.
  3. All robots will be tested after reassembly to confirm its functionality.
    1. Test will be conducted using the Arxterra App
      1. Robot should be able to go forwards
      2. Robot should be able to go backwards
      3. Robot should be able to do a right turn
